Experimental vacuum coating equipment is suitable for any color of plastic, ceramic, resin crafts, glass by vacuum coating after all plating gold, silver, colorful, red, purple, blue, grey, black and other colors, can improve the grade of products, the appearance of the more luxurious effect. Application: used in vacuum coating machine is mainly used for the surface coating of experimental teaching, scientific research, electronic components, and paint manufacturing industry. Equipment characteristics: small test of vacuum coating machine has the characteristics of beautiful appearance, compact structure, performance varied, easy operation and reliable, low power consumption. Can realize the evaporation, magnetron sputtering, plating process. Can be manual, semi-automatic, and fully automatic.
| Mode | HCLB-500 |
| Vacuum chamber | Φ500×H600mm |
| Coating | Semi-transparent,gold,silver,red,blue,green,grey,black,rainbow color,etc. |
| Power supply | DC power supply,MF power supply,electrical arc power supply,filament (power) supply, active power supply, plused bias power supply |
| Vacuum chamber structure | ertical single(side front) door(double water jacket type water cooling or sink type cooling), pump system postposition |
| Vacuum system | Molecular pump + Quasi oil free vacuum system for direct coupled rotary vane pump |
| Ultimate vacuum | 5.0×10-5Pa（No-loading,clean chamber） |
| Sustrate diamension | Φ120mm |
| Heating system |
Room temperature to 500 ℃ adjustable and controllable(PID control) ,heating by stainless steel heater pipe |
| Workpiece rotary |
Top rotary/bottom rotary+public rotation and self-rotations frequency conversion stepless controllable and adjustable,0-20 shift/min |
| Thickness rate | ≤±（1.5～5.0）% |
| Sputtering target |
Two Multi-arc,MF twin targets or flat target can be choiced |
| Pumping time |
No-loading from air to 5×10-2pa ＜6mins. |
| Workpiece motion mode |
6 axis/8 axis/9 axis Public rotation/Frequency control |
|
Control mode |
Manual/Automatic all-in-one mode, Touching screen+PLC |
| Remark | We can design the dimension of the vacuum chamber according to customer’s demand. |
Mainly used in scientific research, teaching.
